Quality Is Our Attitude
| 2L Series | 2L-10 | 2L-15 | 2L-20 | 2L-25 | 2L-35 | 2L-40 | 2L-50 |
| US Series | US-10 | US-15 | US-20 | US-25 | US-35 | US-40 | US-50 |
| Orifice Size | 17 | 17 | 17 | 22 | 30 | 30 | 50 |
| Port Size | 3/8” | 1/2” | 3/4” | 1” | 1-1/4” | 1-1/2” | 2” |
| Medium | Hot Water, Steam | ||||||
| Action | Servo Pilot Operated | ||||||
| Function | 2 Way, Normally Closed | ||||||
| Body Material | Brass, Stainless Steel | ||||||
| Seal Material | PTFE | ||||||
| Pressure Range | 0.1 to 1.5 MPa | ||||||
| Temp. Range | PTFE: -20 to +180℃ | ||||||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | ||||||
