| Model | SLG5404-15 | SLG5404-20 | SLG5404-25 |
| Working Medium | Air,Water, Oil | ||
| Acting Type | Pilot Type | ||
| Orifice | 12mm | 20mm | 25mm |
| Jiont Size | G1/2" | G3/4" | G1" |
| Workig Pressre (Mpa) | Air:0.1-5.0 Liquid:0.1-5.0 | Air:0.1-4.0 Liquid:0.1-2.5 | Air:0.1-4.0 Liquid:0.1-2.5 |
| CV Value | 2 | 5 | 10 |
| Max Pressure | 7. 5Mpa | 6.0Mpa | |
| Working Temperature | -10C-150 | ||
| Power Consumption | AC:5.5VA,DC:9W | ||
| Body Material | Brass | ||
| Seals | PTFE | ||
